ERKO HG200 Busbar Bending Machine

Description

ERKO HG 200 busbar bending station for sale. Bend copper & aluminium busbars up to 200mm wide, 15mm thick. 30kN force, hydraulic system.

Precision Busbar Bending Machine – Hydraulic – Industrial Grade

The ERKO HG 200 Busbar Bending Station is a high-precision hydraulic bending machine designed for accurate forming of aluminium and copper busbars used in electrical panel and switchgear manufacturing.

This machine is ideal for electrical contractors, switchgear manufacturers, and industrial fabrication workshops requiring repeatable, high-quality bending results.

🚀 Key Features

• ✔️ Dedicated busbar bending station (high precision)
• ✔️ Handles large busbars up to 200mm width
• ✔️ Angle compensation system for material flexibility
• ✔️ Hydraulic operation with efficient electric unit
• ✔️ Ergonomic worktop for long busbars
• ✔️ Compact yet robust industrial design

The ERKO HG 200 is designed specifically for:

• Precision bending of copper and aluminium busbars
• Consistent angle forming up to 90°
• Handling large and long busbars with stability
• Accurate repeatable bending with compensation for material elasticity

Its special worktop design ensures stable handling of long busbars, making it ideal for professional electrical fabrication environments.

📦 Included Equipment

• ✅ Bending Station
• ✅ Punching Station
• ✅ Shearing (Cutting) Station
• ✅ Length Stop - 200mm
• ✅ Insert for repeatable bending (with limit switch)
• ✅ Busbar Cutter

⚙️ Technical Specifications

🔹 Busbar Capacity

• Width Range (cut busbars): 50 – 180 mm
• Width Range (bent busbars): 50 – 200 mm
• Thickness Range: 5 – 15 mm

🔹 Bending

• Max Bending Angle: up to 90°
• Minimum Internal Bend (C profile): 70 mm
• Standard Bending Radii: R5, R8, R10, R12, R15, R20

🔹 Hydraulic & Power

• Force: 30 kN @ 400 bar
• Power Supply: 3 Phase 400V / 230V
• Motor Power: 1.68 kW

🔹 Dimensions & Weight

• Dimensions (L x W x H): 1200 x 1230 x 1274 mm
• Weight: 450 kg

⚙️ Advanced Features

• Adjustable bending angle indicator with compensation system
• Ergonomic worktop design for long busbars
• Easy-to-use control panel for quick setup
• Low energy consumption hydraulic unit
• Stable and robust construction

🔧 Tooling & Inserts Available

• Bending inserts (HG 201 series):
• HG201-G20 (15–20mm thickness, 50–150mm width)
• HG201-G15 (8–15mm thickness, 50–200mm width)
• HG201-G8 (5–8mm thickness, 50–200mm width)
• Cutting insert: HG205
• Additional inserts available on request

🏭 Typical Applications

• Busbar fabrication
• Electrical panel production
• Switchgear manufacturing
• Power distribution systems
• Industrial electrical installations

💡 Why Choose the ERKO HG 200?

• ⚡ High precision bending with compensation system
• 🔩 Handles large and thick busbars
• 🎯 Repeatable, accurate results
• 🛠️ Professional industrial design
• 📐 Optimised for long busbar handling

This machine is ideal for companies requiring high-quality bending with maximum control and consistency.

📩 Contact us for pricing, lead time, or full specification details.

Note: Specifications and information provided in each listing are supplied in good faith; however, their accuracy cannot be guaranteed.
