2007 Altendorf WA 80 Sliding Table Saw

Altendorf WA 80 Sliding Table Saw

Machine Type: Panel Saw/Sliding Table Saw

Year: 2007

Condition: Good

Technical Specifications

Saw blade lift: Electrical

Saw blade angle tilting: Electrical

Saw blade readout: Digital readout

Dimension of sliding table: 3100 mm

Gross cut capacity: 3100 mm

Width of cut between saw blade and rip fence: 1300 mm

Tilting saw group: 0-45°

Diameter of main saw blade: 400 mm

Max cutting height 90°/ 45°: 130mm/87mm

Speed of main saw spindle: 3000/4000/5000 r.p.m

Main saw motor power: 5.5 kw

Main spindle diameter: 30 mm

Diameter of scoring saw blade: 120 mm

Speed of scoring saw spindle: 8000 r.p.m

Scoring saw motor power: 0.75 kw

Scoring saw spindle diameter: 22 mm

Electrical Connection: 400V/3phase

Gross weight: 1100kg

Overall dimension: 3250x3150x900 mm
