Citizen Miyano BNJ-51 CNC Automatic Lathe

Citizen Miyano BNJ-51 CNC Automatic Lathe

Machine Type: Fixed Headstock Type CNC Automatic Lathe

Control: Fanuc Series Oi-TF

Cutting Hours: 3590hrs

Condition: Excellent

Includes

Iemca Kid 80 Barfeed

Parts Conveyor

Swarf Conveyor

Parts Catcher

Mirror Turning

Collet Chuck on Spindle 1

Collect Chuck on Spindle 2

6" 3 Jaw Hydraulic Chuck

8 x Driven Toolholders

Static Toolholders

Technical Specifications

Max Machining Length: 100mm

Standard Turning Diameter Spindle 1: 51mm

Standard Turning Diameter Spindle 2: 42mm

Chuck Size Spindle 1: 6"

Chuck Size Spindle 2: 5"

No. of Spindles: 2

Spindle 1 Speed Range: 5000rpm

Spindle 2 Speed Range: 5000rpm

Inner Diameter of Draw Tube(Sp 1): 52mm

Inner Diameter of Draw Tube(Sp 2): 43mm

No. of Turrets: 2

Turret 1 Type: 12 Station

Turret 2 Type: 8 Station

Square Tool Shank Height: 20mm Sq.

Drill Shank Diameter: 25mm

Driven Tool - Turret 1: 12 Stations

Driven Tool - Turret 2: 4 Stations

Driven Tool Speed - T1: 6000rpm

Drive Tool Speed - T2: 3000rpm

X1 Axis Travel: 165mm

Z1 Axis Travel: 246mm

Y1 Axis Travel: 80mm (+/-40mm)

X2 Axis Travel: 85mm

Z2 Axis Travel: 590mm

Rapid Feeds(X1,Z1,X2,Z2): 20m/min

Rapid Feeds(Y1): 12m/min

Spindle 1 Drive Motor: 15kW

Spindle 2 Drive Motor: 7.5kW

Turret 1 Driven Tool Motor: 2.2kW

Turret 2 Driven Tool Motor: 0.75kW

Power Capacity: 33kVA

Machine Only Dimensions: 2840x1560x1700mm

Machine Weight: 5300kg
