€6,000 + VAT

2009 Brevetti Motta C 16 Alu Mitre Saw


Cork, Ireland

orCall +353 838108745


2009 Brevetti Motta C16 Alu Miter Saw

Description The Brevetti Motto C16 Alu Miter Saw is an electropneumatic double mitring saw for 45 degree cuts. at both ends in aluminium profiles of any shape and kind. Cutting is preformed by 2 circular carbide saw blades with a max diameter of 350mm. Bore size is 32mm. Year: 2009

Technical Specifications Max Cutting Width: 85mm Max Cutting Height: 100mm Blade Size: 300 to 350mm Diameter. Bore Diameter: 32mm Blade Rotation Speed: 3400rpm Extraction Connection: 2 x 100mm Diameter Ferrules Supply Voltage: 380V 3 Phase Total Installed Power: 3kW Compressed Air Requirement: 6 bar Machine Dimensions (L x W x H): 800 x 1080 x 1540mm Machine Weight: 340kg


ManufacturerBrevetti Motta
ModelC 16 Alu
Stock Number00216
Max Cutting Width85mm
Max Cutting Height100mm
Blade Size300 to 350mm Diameter.
Bore Diameter32mm
Blade Rotation Speed3400rpm
Extraction Connection2 x 100mm Diameter Ferrules
Supply Voltage380V 3 Phase
Total Installed Power3kW
Compressed Air Requirement6 bar
Machine Dimensions (L x W x H)800 x 1080 x 1540mm
Machine Weight340kg
