€12,000 + Vat
Hansford Model 1020 Die Handler
Description
Hansford Model 1020 Die Handler
Machine Type: Die Handler
Condition: Very Good
Technical Specifications
Capacity: 20T
Lower Platen Size: 610 x 1090mm(24"x43")
Shut Height: 240mm(9.5")
Travel of Upper Platen: 510mm(20")
Opening Height: 765mm (30")
Turns/Inch in Manual: 48
Turns/Inch Try-out: 344
Vertical Powered Movement: 330mm/min(13"/min)
Rotation of Platen: 240 Turns/Inch per 360deg
Locking Position of Upper Platen: 0 & 180deg
Max Weight of Die: 1360kg(3000lbs)
Max Torque: 9000lbs/Inch
Max Try-out Force: 20T
Power: 400V/3ph
Motor: 1.5hp
Dimensions: 1980x1220x1830mm
Weight:1590kg
Specifications
| Manufacturer | Hansford |
| Model | Model 1020 Die Handler |
| Condition | Used |
| Machine Type | Die Handler |
| Condition | Very Good |
| Capacity | 20T |
| Lower Platen Size | 610 x 1090mm(24"x43") |
| Shut Height | 240mm(9.5") |
| Travel of Upper Platen | 510mm(20") |
| Opening Height | 765mm (30") |
| Turns/Inch in Manual | 48 |
| Turns/Inch Try-out | 344 |
| Vertical Powered Movement | 330mm/min(13"/min) |
| Rotation of Platen | 240 Turns/Inch per 360deg |
| Max Weight of Die | 1360kg(3000lbs) |
| Max Torque | 9000lbs/Inch |
| Max Try-out Force | 20T |
| Power | 400V/3ph |
| Motor | 1.5hp |
| Dimensions | 1980x1220x1830mm |
| Weight | 1590kg |
