XYZ Edge 3000 CNC Milling Machine
Sold
Description
XYZ Edge 3000 CNC Milling Machine
Machine Type: CNC Toolroom Milling Machine
Control: Prototrak Edge
Controlled Axis: 2
DRO Axis: 2
Condition: Very Good. (College Machine, New Prototrak Edge Control)
Includes
Machine Vice
Machine Light
Coolant Splash Tray
Align Power Drawbar
Coolant Equipment
Technical Specification
Table Size: 305 x 1270mm
Powered Axis: X & Y & Z
DRO Axis: X & Y
Longitudinal Travel: 863mm
Cross Travel: 406mm
Knee Vertical Travel: 406mm
Quill Travel: 127mm
Quill Diameter: 105mm
Spindle Motor: 5HP
Spindle Speeds: 10-3600rpm
Spindle Taper: ISO40
Spindle Nose to Table: 50-457mm
Max Throat Depth: 610mm
Max Table Load: 550kg
Machine Dimensions(Approx): 1700 x 2000 x 2200mm
Machine Weight: 1650kg
Specifications
| Manufacturer | XYZ |
| Model | Edge 3000 CNC Milling Machine |
| Condition | Used |
| Machine Type | CNC Toolroom Milling Machine |
| Control | Prototrak Edge |
| Controlled Axis | 2 |
| Table Size | 305 x 1270mm |
| DRO Axis | X & Y |
| Longitudinal Travel | 863mm |
| Cross Travel | 406mm |
| Knee Vertical Travel | 406mm |
| Quill Travel | 127mm |
| Quill Diameter | 105mm |
| Spindle Motor | 5HP |
| Spindle Speeds | 10-3600rpm |
| Spindle Taper | ISO40 |
| Spindle Nose to Table | 50-457mm |
| Max Throat Depth | 610mm |
| Max Table Load | 550kg |
| Machine Weight | 1650kg |
