Bryden Tubular Rivet Clincher Mark 2
Sold
![Used Bryden Tubular Rivet Clincher Mark 2](https://i.machineryhost.com/8b6dd7db9af49e67306feb59a8bdc52c/25a508fef28d1df7c9f4919ef837b38a/large-used-bryden-tubular-rivet-clincher-mark-2.jpg)
Description
Bryden Tubular Rivet Clincher Mark 2
Machine Type: Rivet Clincher
Condition: Good
Notes: No Loading Facilities on Site
Technical Specifications
Power Source: Pneumatic
Output Force at 7 Bar: 2.25T
Tooling Stroke (Max): 20mm
Access Gap (approximate); 40mm
Rivet Capacity (Shank Diameter): 3-10mm
Throat Depth: 178mm
Jaw Width: 60mm
Working Line Pressure: 0-10 Bar
Air Consumption per Cycle: 1.57L/cycle
Recommended Compressor Size: 100L/min
Cycles per Minute (approx Speed): 30
Specifications
Manufacturer | Bryden |
Model | Tubular Rivet Clincher Mark 2 |
Condition | Used |
Machine Type | Rivet Clincher |
Condition | Good |
Power Source | Pneumatic |
Tooling Stroke (Max) | 20mm |
Rivet Capacity (Shank Diameter) | 3-10mm |
Throat Depth | 178mm |
Jaw Width | 60mm |
Working Line Pressure | 0-10 Bar |
Air Consumption per Cycle | 1.57L/cycle |
Recommended Compressor Size | 100L/min |
