HAAS TM-1 CnC Toolroom Milling Machine
Sold
Description
HAAS TM-1 CnC Toolroom Milling Machine Type: 3 Axis CNC Toolroom Milling Machine Year: 2005 Serial Number: 42458 Hours: 700 hrs (Genuine Hours) Control: HAAS CNC Control Table Size: 1213 x 267mm Travels (X): 762mm Travels (Y): 305mm Travels (Z) 406mm Max Spindle Speed: 4000rpm Spindle Taper: BT40 Bought for a contract that didn't materialise
Specifications
| Manufacturer | HAAS |
| Model | TM-1 |
| Year | 2005 |
| Condition | Used |
| Serial Number | 43458 |
| Stock Number | 00206 |
| Year | 2005 |
| Hours | Approx 700hrs (Genuine Hours) |
| Max Spindle Speed | 4000 RPM |
| Spindle taper | BT40 |
| Spindle Max Rating | 5.6kW |
| Spindle Max Torque | 45 Nm @ 1200rpm |
| Table size | 1213 x 267mm |
| Travels (X) | 762mm |
| Travels (Y) | 305mm |
| Travels (Z) | 406mm |
| Max Part Weight | 454 KG |
| Spindle Nose to Table Min | 102mm |
| Spindle Nose to Table Max | 508mm |
| Rapids (X) | 5.1m/min |
| Rapids (Y) | 5.1m/min |
| Rapids (Z) | 5.1m/min |
| Machine Dimensions (L x W x H) | 2540 x 1990 x 2520mm |
| Machine Weight | 2042kg |
