Arboga A2508U Milling & Drilling Machine
Sold
Description
Arboga A2508U Milling & Drilling Machine
Machine Type: Milling & Drilling Machine
Year: Unknown
Condition: Very Good
Power: 3 Phase
Includes
Sony 2 Axis DRO
Powerfeed on Table
Tapping Head
Drill Chuck
Face Mill
Selection of other Tooling
Technical Specification
Drilling Capacity: 25mm
Thread Cutting: Up to M16
Table Size: 560 x 240mm
Throat Depth: 258mm
Spindle Speeds: 100-2900rpm
Quill Stroke: 115mm
Dist from Spindle Nose to Table: 500mm
Column Diameter: 140mm
Longitudinal Travel: 395mm
Cross Travel: 165mm
Spindle Taper: MT3
Motor Power: 0.75kW
Dimensions: 800x550x1600mm
Weight: 270kg
Specifications
| Manufacturer | Arboga |
| Model | A2508U Milling & Drilling Machine |
| Condition | Used |
| Serial Number | 7323568 |
| Machine Type | Milling & Drilling Machine |
| Year | Unknown |
| Condition | Very Good |
| Power | 3 Phase |
| Drilling Capacity | 25mm |
| Thread Cutting | Up to M16 |
| Table Size | 560 x 240mm |
| Throat Depth | 258mm |
| Spindle Speeds | 100-2900rpm |
| Quill Stroke | 115mm |
| Column Diameter | 140mm |
| Longitudinal Travel | 395mm |
| Cross Travel | 165mm |
| Spindle Taper | MT3 |
| Motor Power | 0.75kW |
| Dimensions | 800x550x1600mm |
| Weight | 270kg |
