€19,115 + VAT

RHTC PPCD-25 C-Frame Press

5

Netherlands

orCall +353 838108745

Description

RHTC Presses PPCD-25


Our 25 ton C-frame press is suitable for performing work involving deep-drawing, forming and stamping.

Equipped with a lower table with T-grooves, an adjustable piston stroke (with end-stroke switches), two speeds and a pressure switch. This 25 ton C-frame press has a manual and semi-automatic mode. Furthermore, you can operate the press by means of the two-hand push buttons.


These C-frame presses of RHTC consist of an electro welded structure made out of S355JR steel and are designed for stamping, die-cutting and forming / to incorporate in automated production lines. Made in Europe.


These C-frame press models are equipped with a mechanized lower table with T-grooves. The cylinder is mechanized at the end to adapt tools and moulds.

The cylinder stroke is easy to adjust with the end-stroke switches on the side of the presses.

Operation of these PPCD-models is carried out by a two-hand push button with level IV security module. The safety for these C-frame models is guaranteed by two fixed lateral protection screens and a front opening of 600 mm.

The control panel features a selector for manual or semi-automatic operation and a selector for the two different cylinder speeds (fast approach speed and slow working speed). It also contains a pressure switch and manometer.


Technical specifications:

Force [tn]: 25

Motor power [kw]: 1.5

Throat depth [mm]: 250

Working speed [mm/sec]: 3

Approaching speed [mm/sec]: 21

Return speed [mm/sec]: 27

Maximum pressure [bar]: 160

Piston stroke [mm]: 250

Lower table size [mm]: 400 x 400

Max. vertical light [mm]: 400

Working height [mm]: 850

Total length [mm]: 960

Total width (frontal) [mm]: 740

Height [mm]: 2090

Weight [kg]: 950


Features:

Equipped with a lower table with T-grooves

The cylinder is mechanized at the end to adapt tools and moulds

The cylinder stroke is easy to adjust with the end-stroke switches

Manual / semi-automatic work mode

Two cylinder speeds

Pressure switch and manometer

Operation by two-hands push buttons


Optional accessories:

Geometry adapted to your requirements (for example a larger table, larger vertical light or larger piston stroke)

Higher speeds with a different pump

Hydraulic ejector

Punching tool-set for diameters from 6 up to 100 mm with anti-deformation elastic hold-down

415 mm folding tool-set (Promecam clamping system)

Cooling equipment for the hydraulic group by an air-oil cooling system



Specifications

ManufacturerRHTC
ModelPPCD-25 C-Frame Press
ConditionNew
Force [tn]25
Motor power [kw]1.5
Throat depth [mm]250
Working speed [mm/sec]3
Approaching speed [mm/sec]21
Return speed [mm/sec]27
Maximum pressure [bar]160
Piston stroke [mm]250
Lower table size [mm]400 x 400
Max. vertical light [mm]400
Working height [mm]850
Total length [mm]960
Total width (frontal) [mm]740
Height [mm]2090
Weight [kg]950
