Almi AL150HS 2 IN 1 PIPE GRINDER/NOTCHER
Description
ALMI AL150HS 2 IN 1 PIPE GRINDER/BELT SANDER
Description
The new AL150HS has a belt speed of 45 m/s due to its unique transmission. Due to this high speed, the service life of the sanding belt is 2 to 3 times longer.
2 in 1 Pipe Grinder
The new AL150HS has a belt speed of 45 m/s due to its unique transmission. When you open the rear cover, you can also use the pipe grinder as a belt sander, ideal for deburring cut profiles. The AL150HS has the option of being operated by means of two handwheels or by means of a lever. Both options are available on the machine. With the AL150HS you can grind material from Ø20 to Ø114.3. The cross support and the slide with rotatable clamp are infinitely adjustable. This allows all pipe profiles to be ground at any desired angle from 20° to 90°. The AL150HS grinds square, rectangular and round pipes with different wall thicknesses and is suitable for all common material types. It is now even easier to adjust the grinding belt with the supplied hex wrench. The grinding belt can be quickly tensioned and grinding rollers can be changed in just a few seconds.
High Speed Grinding
Thanks to new developments, ALMI has been able to achieve a grinding speed of 45 m/s with the updated AL150HS. As a result, the sanding belt has a longer service life, and faster grinding results in less heat in the material, resulting in less discolouration and fine dust.
Sustainable
All ALMI pipe grinders are produced by professional craftsmen. All parts are provided with a protective coating, which guarantees a long service life.
Technical Specification
Motor: 4 kW
Connection: 400V, 3 Phase
Belt speed: 45 m/s, 4300 rpm
Belt size: 100×2000/150 x 2000 mm
Grinding diameters: Ø20-Ø114.3
Grinding angle: 20 – 90º
Operation: Lever and handwheel operation
Weight: 275 kg
Specifications
Manufacturer | Almi |
Model | AL150HS 2 IN 1 PIPE GRINDER/NOTCHER |
Condition | New |
Motor | 4 kW |
Connection | 400V, 3 Phase |
Belt speed | 45 m/s, 4300 rpm |
Belt size | 100×2000/150 x 2000 mm |
Grinding diameters | Ø20-Ø114.3 |
Grinding angle | 20 – 90º |
Operation | Lever and handwheel operation |
Weight | 275 kg |
